Brand: Foton AUMARK E
Vehicle model:AUMARK-T33 /AUMARK-T38/AUMARK-T43
Cabin: Single row/ W1800/ left rudder,Single row/ W1995/ left rudder,Single row/ W1800/left rudder
download
Whatsapp
| Vehicle model | AUMARK-T33 | AUMARK-T38 | AUMARK-T43 | |
| Cabin | Single row/ W1800/ left rudder | Single row/ W1995/ left rudder | Single row/ W1800/left rudder | |
| Whole vehicle main dimensions | Overall dimensions (LxWxH) mm | 5875×1915×2230 | 6785×2130×2330 | 5975×1925×2230 |
| Wheel base(mm) | 3360 | 3800 | 3360 | |
| Weight data | Curb weight(kg) | 2100 | 3110 | 2300 |
| Gross vehicle weight（kg） | 4485 | 8500 | 5500 | |
| Persons in cab | 3 | 3 | 3 | |
| Whole vehicle main performance | Max. speed（km/h） | 95 | 95 | 95 |
| ENGINE | Model | BJ493ZLQV1 | YC4D130-33 | 4J28TC |
| Emissions standards | EuroⅢ | EuroⅢ | EuroⅣ | |
| Displacement（L） | 2.771 | 4.214 | 2.771 | |
| Rated Power（kw/rpm） | 80 | 96 | 81 | |
| Max torque （N.m/rpm） | 280 | 380 | 280 | |
| Gearbox | Model | JC5-28 | 6T120 | 6T100 |
| Front axle | Type/ Mainreducetion ratio | 2.2T | 2.5T | 2.2T |
| Rear axle | Type/ Mainreducetion ratio | 5.0T/6.142 | 6.0T/5.286 | 5.0T/5.375 |
| Suspension | Front suspension/ Leaf spring number | 3+1 | 9 | 3+1 |
| Rear suspension/ Leaf spring number | 6+7 | 11+7 | 6+7 | |
| Brake system | Service brake | Drum pneumatic braking | Drum pneumatic braking | Drum pneumatic braking |
| Parking brake | Central drum brake | Brake gas brake | Brake gas brake | |
| Auxiliary brake | Engine exhaust brake | Engine exhaust brake | Engine exhaust brake | |
| Wheels and tyre size | 6+1/( 7.00R16) | 6+1/( 8.25R16) | 6+1( 7.00R16) | |
Aumark is a medium & high end light-duty truck brand under Foton Motor group, the Chinese largest commercial vehicle supplier. Foton Motor has collection of years of experience in truck building and absorbed the leading technology from Europe and America. Foton Aumark, developed to meet the needs of efficient logistics and transportation for users around the world, has many characteristics such as performance leading, environmentally friendly energy-saving, model-rich and adapting to the global light truck users of a variety of logistics scenes.
Aumark E is designed for meeting the global user’s pursuit of an efficient and worry-free city logistics.
Aumark E :Utility，Economical，Reliable，Safe; On Demand to The High-frequency Urban Logistics Scenes.
