Model
|
Foton Bus 56+1+1
|
| Dimension (LxWxH)(mm) |
12000*2550*3860 |
| G.V.W.(kg) |
18000 |
| Seat No. |
56+1+1 |
| Wheelbase(mm) |
6000 |
| Min. Ground Clearance(mm) |
180 |
| Max. Gradeability(%) |
≥30 |
| Max. Speed (km/h) |
≥125 |
| Fuel Tank Capacity(L) |
450 |
| Fuel Consumption(L/100km) |
≤26 |
| Engine Model |
P11C-UJ、ISME360 30、WP10.336、WP10.375 |
| Max Power/Rev. (KW (ps) /rpm) |
276（375）/2200 |
| Gear Box |
S6-160 |
| Clutch |
SACHS φ430 pull clutch |
| Front Axle |
domestic front axle |
| Rear axle |
North-Benz 13T |
| Suspension System |
Air suspension |
| Steering System |
ZF8098 Power steering |
| Tyre |
295/80R22.5 |
| Air Conditioner |
Overhead non-independent air-conditioner (31000 kcal) |
| Door and Door Pump |
Remote control door lock |
| Body Interior Trimming |
Luxury profiled interior trimming |
| Option |
Digital clock, driving recorder,automatic fire extinguisher for engine compartment, stainless wheel cover |
Spiritual driving control, quality and enjoyment
Adoption of large corner front axle + excellent synchronization tuning of front and rear axles, greatly improving the vehicle’s passability;
High space utilization rate, seating capacity 55+1;
Standard equipped with hydraulic retarder, braking performance is efficient and reliable;
Multi-functional adaptive driver’s seat, more comfortable driving for the driver;
Fully enclosed cockpit, short handle instrument panel, easy to drive and operate.
Elegance on the inside, enjoying comfort
Bilateral luxury luggage racks in Rhine White, aesthetically pleasing and stylish, making it easy for passengers to place their luggage;
The floor, dome and dashboard ambient light clusters are full of visual tension;
Optional multi-color variable starry sky roof, feel the comfort of travel.
Full-time online intelligent navigation
The iFoton intelligent vehicle management system is compatible with a variety of service functions such as navigation, multimedia entertainment, vehicle safety management monitoring, etc., maximizing the comfort and practicality of the bus.
Complemented by in-vehicle Wi-Fi, in-vehicle Bluetooth, front and rear seat USB charging interface and other configurations, passengers are more convenient to use.
Economic safety and enjoyment of peace of mind
Active safety: front and rear disc axles, AEBS, ESC, tire pressure monitoring, CAN bus, all-round safety assurance;
Tilting windshield + full-bearing body, reducing vehicle resistance, improving driving speed, and reducing fuel consumption of the whole vehicle by 5%;
Standard equipped with hydraulic retarder, energy saving and consumption reduction.
