Overall dimensions (L x W x H) mm:5541×2030×1905
Cargo Box Internal Dimension (L x W x H) mm: 1560×1650×530
Wheelbase (mm): 3355
Gross vehicle weight (kg): 3000
Engine model: 4F20TC +48V
download
Whatsapp
| TUNLAND V | |||
| Cab form | Double Cabin | ||
| Drive type | 4×4 | ||
| Dimension | overall dimensions
(L x W x H) mm |
5541×2030×1905 | |
| Cargo Box Internal Dimension
(L x W x H) mm |
1560×1650×530 | ||
| Wheelbase (mm) | 3355 | ||
| Mass | Gross vehicle weight (kg) | 3000 | |
| Curb weight (kg) | 2200 | ||
| Rated load mass (kg)/Number of passengers | 500kg/5 | ||
| Power system | Engine | Engine model | 4F20TC +48V |
| Emission | Euro V / Euro VI | ||
| Displacement(L) | 2.0L | ||
| Power(kw/ps) | 120kw/160ps | ||
| Max torque(N.m/rpm) | 450/1800-2600 | ||
| Transmission | ZF 8HP50 | ||
| Chassis system | Rear axle（Type/Main reduction ratio) | 2.2t/3.91 | |
| Suspension | Front: Double wishbone independent suspension, Rear: Multi link integral axle suspension | ||
| Tyre Model | 265/70R18 | ||
|
Other configurations and performance |
Minimum ground clearance(mm) | 240 | |
| Maximum speed(km/h) | 160 | ||
| Maximum gradeability(%) | 30 % (2WD)/60 % (4WD) | ||
Product feature |
Foton brand new P4 pickup designed from new platform, equipped with AUCAN 2.0T+48Vhybrid system, with a maximum power of 120kW and a maximum torque of 450N m, matched with ZF 8AT gearbox. A large front grille with full LED split blackened headlights and 2030mm ultra-wide body adopts a brand-new American off-road pickup truck appearance design concept.
Interior embracing three-dimensional cockpit, racing-style seat + 12-way electric adjustment for the main driver, front seat ventilation and heating, automatic constant temperature air-conditioning. The 14.6-inch intelligent central control large screen is matched with Carplay and Carbit system, AI intelligent voice interaction system at the same time. Foton Pickup equipped dual airbags + side airbags + side air curtains + pre-tightened seat belts，and L2.5 intelligent driving system. |
||
FOTON TUNLAND V combines FOTON’s numerous technical achievements, with a front double-wishbone and rear multi-link suspension structure that meets the demands of strong off-road capabilities and high load-bearing capacity while maintaining luxurious driving comfort. As FOTON’s first product to feature a hybrid power system, the TUNLAND V has a power peak torque of up to 450 N·m. It achieves a 10% reduction in fuel consumption through Auto Start-Stop, energy recovery systems, and an ultra-high-pressure combustion system, with a maximum thermal efficiency of 50%. Additionally, to meet different powertrain requirements of global customers, TUNLAND V will also be equipped with FOTON’s DHT Hybrid Power System, pure electric and extended-range electric systems, with a maximum battery capacity of 100 KWh and a total driving range of up to 900 km, achieving high performance, multiple powertrain options, long endurance, and high torque.
In terms of intelligence, FOTON TUNLAND V is equipped with intelligent auxiliary driving devices such as Adaptive Cruise Control, Automatic Emergency Braking, and Lane Keeping Assist System and etc., achieving L2.5 autonomous driving. In terms of comfort and safety, it features a 14.6-inch intelligent display, intelligent voice interaction system, and ambient light intelligent linkage, providing full-scenario intelligent in-car services and an immersive experience. The overall NVH performance has been improved by 15%, and the main and co-pilot positions are equipped with six airbags. Both active and passive safety have been comprehensively upgraded to provide users with all-round protection.
Foton brand new P4 pickup designed from new platform, equipped with AUCAN 2.0T+48Vhybrid system, with a maximum power of 120kW and a maximum torque of 450N m, matched with ZF 8AT gearbox. A large front grille with full LED split blackened headlights and 2030mm ultra-wide body adopts a brand-new American off-road pickup truck appearance design concept.
Interior embracing three-dimensional cockpit, racing-style seat + 12-way electric adjustment for the main driver, front seat ventilation and heating, automatic constant temperature air-conditioning. The 14.6-inch intelligent central control large screen is matched with Carplay and Carbit system, AI intelligent voice interaction system at the same time. Foton Pickup equipped dual airbags + side airbags + side air curtains + pre-tightened seat belts，and L2.5 intelligent driving system.
