Foton Miler 4.5T

Brand			Foton Miler
Model			BJ 1035 V5JV5-05
Body			Single Cabin	Single Cabin
Engine	Model		DAN20L	DAN20L
	Emission		Eur. II	Eur. II
	Fuel type		Gasoline	Gasoline
	Power ( KwZrpm )		106 / 6000	106 / 6000
	TDrque ( N-mZrpm )		195 / 4400	195 / 4400
	Displacement (ml)		1998	1998
Transmission			DAT25R ( 5MT )	DAT25R ( 5MT )
Size parameter
Design body external dimension (mm)- Flat Box			5165 x 1950 x 2135	5585 x 1950 x 2135
Cargo compartment Dimension (mm)- Flat Box			5165 x 1950 x 2135	3815 x 1850 x 400
Design body external dimension (mm)- Closed cargo Box			5200 x 1950 x 2725	5620 x 1950 x 2725
Cargo compartment Dimension (mm)- Closed cargo Box			3380 x 1850 x 1800	3815 x 1850 x 1800
Wheel base (mm)			2700	3000
Capacity parameter
GVW (kg)			3495	3495
Kerb weight (kg) – Chassis			1455	1485
Kerb weight (kg) – Flat Box			1765	1815
Loading weight (kg) ( including persons )			2040	2010
Payload			2T	2T
Capacity ( Person )			2	2
Front axle			1T	1T
Rear axle			2.5T	2.5T
Rear axle ratio			5.375	5.375
Basic configuration
Interior trim		Half-inclusive	•	•
Brake clearance self – adjusting arm			.	•
ABS			•	•
Brake type		Front	Disk	Disk
		Rear	Drum	Drum
Electronic accelerator pedal			•	•
Parking brake type			Central drum	Central drum
Suspention System		Front	Leaf spring, 3	Leafspring,3
		Rear	Leaf spring, 3+2	Leaf spring, 3+2
EP polymorphic switch			•	•
Fuel tank			Plastic ,60L	Plastic ,60L
Tire Type			185R15	185R15
Central lock			.	.
Electric window			•	.
Remote control			•	•
Automatic headlights			•	•
Electrically adjustable headlights			•	•
Halogen headlights			•	•
Cigarette lighter			.	•
12V power socket			•	•
One-key lock car window lift ( no anti-pinch )			•	.
Door not closed warning			•	•
Forgotten key alarm			•	•
Drivers seat belt not fastened Alarm			•	.
Option configuration
o			o	o
9 inch MP5 + reversing image + bluetooth			o	o
Mechanical shock – absorbing driver’s seat			o	o
Electric air conditioner			o	o
Flat Box			o	o
Cargo Box ( Closed )			o	o
LCD Dashboard			o	o
Daylight			o	o
Electric adjustable rearview mirror			o	o
Reversing radar + Craise			o	o
PU seat			o	o

Foton is the world’s leading, China’s largest commercial vehicle enterprise.

To satisfy the demands of international consumers for urban logistics and transportation, Foton has set many years of truck building experience, absorbed cutting-edge technology from Europe and the US, and created Miler — a high-end light-duty truck brand, which boasts high quality, high performance, high flexibility, high economy and low emission.

Foton Miler’s story

1. Point to the air deflector — emphasizing that Miler is a new generation of products created by FOTON, the single-brand sales champion of Chinese light-duty trucks;

2.The high-end product was created by FOTON with an investment of 400 million yuan over 3 years;

3.Point to the front lamps — they are stylish, built according to modern art aesthetics, and meet the aesthetic standards of the new generation of users;

4.It will always make your eyes shine at first sight;

5.The vehicle has a tough and simple appearance, with more interior space compared to the competitors.

6.Front lamps and its coherent chrome-plated corner design make the front more avant-garde, and the full front design brings you a more powerful sense of visual impact;

7.Introduction to FOTON brand;

8.Diamond LOGO base and Reversing buzzer ensure no blind spots in the field of vision and enhance safety across the board;

9.The design of dual distant light and dual light sources, with high beam diameter of 70 mm and large projection area, makes night driving safer;

10.Introduction to vehicle styling;

11.Point to the front of the vehicle — it incorporates many fashion elements, which meet the aesthetic standards of the new generation of users;

12.Introduction to vehicle color — its fresh and soft bright colors convey a positive attitude towards life;

13.Tiffany blue, the romantic, warm, and fresh color, is the major color tone of the vehicle, which is a noble color between blue and green, known as the world’s most expensive blue, fully reflecting the product class.

Foton Miler Interior

Customized Foton Miler for you
1. Co-creation between factory and customer

20,000+ advice from light-duty truck users has been gathered;
Based on operation big data of Foton‘s millions of urban distribution users both in China and abroad;
“Customer-oriented” and 3 years of co-creation between factory and customer, to build a user-defined super truck.

2.Directional R&D

The R&D team of Foton Research Institute has spent three years building a new technology platform targeting low cost, high efficiency, high income, and high comfort, aiming at more than 20 subdivided urban distribution scenarios and 80+ working conditions for light-duty trucks.

3.Authority participation

CATARC — China’s automotive R&D authority, is fully involved in the research and development of Miler;
From the initial user investigation, to more than ten times product improvement, to the final vehicle performance verification, Miler, CATARC, and its users achieve comprehensive participation in production, research, and use to create a win-win situation.

4.Extreme road test

The team formed by Miler, Aucan, and CATARC carried out the vehicle performance verification under extreme environments, i.e., plateau (Tanggula Pass, 5,231 m above sea level), high temperature (Turpan, average temperature of 45°C), and cold (Hailar, –40°C) on Miler trucks, as well as 2 million km of comprehensive real-world road testing.

FOTON Miler — a lightweight truck brand for city logistics and distribution

There are more than 700 outlets of sales and service in overseas markets for Foton LDT brand（Aucan engine）, covering more than 80 countries and regions.
