Engine :2.4L
Length / Width / Height / Wheelbase (mm):5380 / 1920 / 2285 / 3110
Cylinders :4
Displacement :2378cc
Maximum speed :145km/h
download
Whatsapp
| View CS2 L 19 Seater | ||
| Dimensions | Length x Width x Height | 5900x 1920x 2320 |
| Wheel Base | 3720 | |
| Total mass | 4035 Kg | |
| Kerb Weight | 2435 Kg | |
| Type of the Last Seat | Foldable | |
| Seat Capacity | 19 | |
| Seating Arrangement | 3+3+3+3+3+4(Foldable) | |
| Ground Clearance | 190 mm | |
| Fuel Tank | 70 Liters | |
| Engine | Model | Cummins ISF 2.8L Diesel Engine |
| Displacement | 2776 cc | |
| Number of Cylinders | 4 | |
| Max. Power Output | 110 KW @ 3600 rpm | |
| Max Torque | 330NM @1400-300rpm | |
| Max Speed(Km/hr) | >=145 | |
| Roof | High | |
| Transmission and Axles | Transmission | 5MT |
| Drive Type | 2WD | |
| Steering type | Hydraulic Power Assisted Rack and Pinion | |
| Suspension & Tyres | Front | Double Wishbone Suspension Type |
| Rear | Leaf Springs Suspension Type | |
| Min.turning Radius | 6.2 m | |
| Tire | 215/75R16C | |
| Wheels | Alloy | |
| Safety | Airbags | Drivers Airbag & Assistant Driver Airbag |
| Brakes | Front ventilated disc and rear drum | |
| ABS+EBD | • | |
| Central Locking | • | |
| Warning Symbols | Seat belt Unfastening and Door Open | |
| Reverse Sensor with Camera | • | |
| Onboard Diagnostics | • | |
| Lamps and Lantern | Front Fog Lamp | |
| Day Time Running Lights | ||
WITH THE CLASSIC, THE ACHIEVEMENTS OF THE FUTURE
After 17 years of quality accumulation, with integration of global landscape design concept in classic vehicles, VIEW set comfort, safety, control and bearing, fashionable large space in one. Two series of wide-body CS2 and narrow-body C2, and 9-16 seats product can meet wider demands for enterprise reception, public transport, logistics and other different business.
Foton presents a modern 15+1 vehicle, with a high level of comfort and functionality for passenger transport.
Modern
With a total distance of 5,380 meters, the foton view cs2 stands out for its comfort for its 15 passengers, thanks to its seats, all retractable and removable, which adds great versatility of use due to the multiple possible configurations.
Security
Brakes with ABS system and electronic brake distribution (EBD), and three-point seat belts. For passenger and driver access, it has two front doors, a sliding side door, and a vertical-opening tailgate.
Inside
The Foton VIEW CS2 is, due to technology, comfort and safety, an ideal minibus for executive passenger transport, for tourism and also as school transport.
Foton VIEW CS2L Interior
